产品概览
The RT088T271-A1 is a high-performance 8.8-inch TFT LCD module designed for professional and industrial applications. It combines a sharp 1280×480 resolution with high brightness, wide viewing angles, and rugged reliability, making it an ideal display solution for systems requiring consistent visual performance in challenging conditions. JicTech ensures quality and supports full customization.
主要功能和优点
Crisp Visuals: 1280×480 resolution with 16.7M colors for detailed graphics and text.
High Brightness & Readability: 500 cd/m² typical brightness ensures clear visibility in various lighting.
广视角： 170°(H)/170°(V) allows viewing from almost any direction without color shift.
Industrial Robustness: Operating temperature range of -20°C to 70°C, suitable for harsh environments.
Reliable Interface: Standard LVDS interface ensures stable signal transmission and easy integration.
Customizable: Flexible options for bonding, connectors, and firmware; small-batch orders available.
典型应用
Automotive: Center consoles, dashboard displays, rear-seat entertainment.
Industrial: Human-Machine Interface (HMI), control panels, test and measurement equipment.
Medical: Patient monitoring devices, diagnostic equipment displays.
Commercial: POS systems, interactive kiosks, gaming machines.
Instrumentation: Weighing scales, network analyzers, power meters.
详细规格
| 类别 | 参数 | 规格 |
|---|---|---|
| 显示屏 | 屏幕尺寸 | 8.8 inches (diagonal) |
| 活动区域 | 209.28(W) × 78.48(H) mm | |
| 决议 | 1280 × 480 pixels | |
| 像素间距 | 0.1635 × 0.1635 mm | |
| 显示模式 | 通常为黑色 | |
| 颜色数量 | 16.7 Million | |
| 表面处理 | AG 25% (Anti-Glare) | |
| 光学 | 亮度（典型值） | 500 cd/m² |
| 对比度（典型值） | 1000:1 | |
| 视角（CR≥10） | 170° (H), 170° (V) | |
| 响应时间（典型值） | 25 ms | |
| 色域（NTSC） | 70% (Typical) | |
| 电气 | 界面 | LVDS (6-bit/8-bit selectable) |
| Power Supply (Typ.) | DVDD: 3.3V, AVDD: 13V | |
| 典型功耗 | ~3.22W (Module), ~2.73W (Backlight) | |
| 背光类型 | LED, Lifetime: 30,000 hours (Typ.) | |
| 机械 | Module Dimensions (Typ.) | 229.6(W) × 97.3(H) × 6.0(D) mm |
| 重量 | 215 grams | |
| 连接器 | CN1: 60-pin (LVDS/Control), CN2: 2-pin (LED) | |
| 环境 | 工作温度 | -20°C 至 +70°C |
| 存储温度 | -30°C至+80°C |
Customization & Service
JicTech is more than a supplier; we are a display solution partner. We offer:
Engineering Support: Collaborate on optical bonding, custom interfaces, or driver board design.
Small Batch Orders: Ideal for prototyping, pilot runs, and specialized projects.
质量保证： Full compliance with reliability testing standards, including shock, vibration, and ESD.
保修： Backed by a 12-month product warranty under normal operating conditions.
联系我们
Ready to integrate this 8.8-inch display into your product? Contact the JicTech sales team today for pricing, sample requests, or to discuss your custom project requirements.
Download this product’s technical documentation and specifications.
单击此处下载：FULL SPEC-RT088T27I-A1
