5.7″ Grayscale TFT LCD Module – 320×240 Parallel Interface
5.7-inch grayscale TFT LCD display module featuring 320×240 resolution with 4:3 aspect ratio, parallel interface, and 16-level grayscale capability. ST7511U driver IC with 12 o’clock viewing direction and wide operating temperature range (-20°C to +70°C). 50,000-hour LED backlight. Ideal for industrial control panels, medical equipment, HMI terminals, and professional instrumentation requiring high-contrast grayscale graphics.
5.7-Inch Grayscale TFT LCD Module – 320×240 with Parallel Interface
This 5.7-inch grayscale TFT LCD module features a 320×240 resolution with a 4:3 aspect ratio and a parallel interface. It is designed for industrial control panels, medical equipment, HMI terminals, and professional instrumentation requiring high-contrast grayscale graphics. The glare surface and wide operating temperature range (-20°C to +70°C) make it an excellent choice for demanding professional applications.
Key Features
- Grayscale Display – Supports 16 gray scales (4BPP), 4 gray scales (2BPP), and 2 gray scales (1BPP) for flexible display quality
- 4:3 Aspect Ratio – 320×240 resolution optimized for industrial HMI and instrumentation displays
- 12 o’clock Viewing Direction – Optimized for standard viewing positions with 6 o’clock gray scale inversion direction
- Parallel Interface – 8-bit parallel data bus with support for both 8080 and 6800 series MCU interfaces
- High Brightness Backlight – 140mA LED backlight with 8.4V~9.9V for excellent readability
- Wide Operating Temperature – -20°C to +70°C for demanding industrial environments
- Glare Surface – High clarity and contrast for professional display applications
- Normally White TFT – Bright, clear display with excellent readability
- 50,000-Hour LED Backlight – Reliable long-life illumination for extended product lifespan
- ST7511U Driver IC – High-performance driver optimized for grayscale TFT displays
- No Touch Panel – Cost-effective solution for applications not requiring touch interaction
Technical Specifications
| Parameter | Specification |
|---|---|
| Size | 5.7-inch diagonal |
| Dot Matrix | 320 x 240 |
| Module Dimension | 160.0 x 109.0 x 7.0 mm |
| Active Area | 115.2 x 86.4 mm |
| Dot Pitch | 0.36 x 0.36 mm |
| Aspect Ratio | 4:3 |
| LCD Type | TFT, Normally White, Transmissive |
| View Direction | 12 o’clock |
| Gray Scale Inversion Direction | 6 o’clock |
| Gray Scale | 16 Gray Scales (4BPP) / 4 Gray Scales (2BPP) / 2 Gray Scales (1BPP) |
| Interface | Parallel (8-bit) |
| Driver IC | ST7511U or Equivalent |
| Backlight Type | LED, Normally White |
| Touch Panel | Without Touch Panel |
| Surface Treatment | Glare |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -30°C to +80°C |
| Supply Voltage (VDD) | 3.0V ~ 3.6V (Typ. 3.3V) |
| Supply Current (IDD) | 20mA ~ 30mA (Typ.) |
| Power Consumption | 66mW ~ 108mW (Typ.) |
| LED Voltage (VLED+) | 8.4V ~ 9.9V (Typ. 9.0V) |
| LED Current | 140mA (Typ.) |
| LED Power Consumption | 1176mW ~ 1386mW |
| LED Life Time | 50,000 Hours |
Pin Interface
| Pin | Symbol | Function |
|---|---|---|
| 1 | GND | System Ground |
| 2 | VDD | Power Supply (3.3V) |
| 3 | NC | No Connection |
| 4 | A0 | Data/Command Select |
| 5 | /WR (R/W) | Write Strobe Signal |
| 6 | /RD (E) | Read Strobe Signal |
| 7-14 | DB0~DB7 | 8-Bit Data Bus |
| 15 | /CS | Chip Select |
| 16 | /RESET (RSTB) | Hardware Reset |
| 17 | IF0 | Interface Mode Select |
| 18 | IF1 | Interface Mode Select |
| 19-22 | NC | No Connection |
Interface Mode Selection
| Mode | MCU Type | Interface Pins Used |
|---|---|---|
| 8080 Parallel | 8080 Series | CS, A0, WR, RD, D[7:0] |
| 6800 Parallel | 6800 Series | CS, A0, R/W, E, D[7:0] |
| 4-Line Serial | – | CS, A0, SCL, SDI |
| 3-Line Serial | – | CS, SCL, SDI |
Backlight Unit (CN2)
| Pin | Symbol | Function |
|---|---|---|
| 1 | VLED+ | LED Anode (Red) |
| 3 | VLED- | LED Cathode (White) |
Grayscale Display Technology
This module is a grayscale TFT display, not a full-color TFT. It supports flexible grayscale configurations:
- 16 Gray Scales (4BPP) – 4 bits per pixel for smooth gradient and detailed imagery
- 4 Gray Scales (2BPP) – 2 bits per pixel for reduced data requirements
- 2 Gray Scales (1BPP) – 1 bit per pixel for simple high-contrast monochrome display
This makes the display ideal for applications requiring high-contrast grayscale graphics with standard 4:3 aspect ratio.
Applications
This grayscale TFT LCD module is designed for a variety of industrial, medical, and professional applications where high-contrast grayscale graphics with 4:3 format are required:
- Industrial Control Panels – HMI interfaces, machine controls, and process monitoring displays
- Medical Equipment – Patient monitors, diagnostic devices, and medical instrumentation
- HMI Terminals – Human-machine interface terminals for factory automation
- Professional Instrumentation – Test and measurement equipment, data loggers, and analyzers
- Security Systems – Access control panels and surveillance system interfaces
- Navigation Systems – Marine and aviation instrument displays
Customization Options
We offer flexible customization to meet specific project requirements:
- Touch Panel – Resistive or capacitive touch panel integration available upon request
- Brightness – Backlight brightness can be customized for different environments
- Interface – Alternative interface options available depending on requirements
- FPC – Custom FPC length, connector type, and pinout available
- Operating Temperature – Extended temperature range versions available for industrial applications
- Surface Treatment – Optional surface treatments including anti-glare or hard coating
- LCM Assembly – Custom mechanical integration and housing solutions available
Selection Guide
When selecting this grayscale TFT LCD module for your project, consider the following factors:
- Display Type – This is a grayscale TFT display (not full-color), optimized for high-contrast monochrome and grayscale graphics with 16-level gray scale capability
- Aspect Ratio – 4:3 format (320×240) ideal for industrial HMI and instrumentation applications
- Viewing Direction – 12 o’clock viewing direction with 6 o’clock gray scale inversion direction
- Interface Compatibility – 8-bit parallel interface supports both 8080 and 6800 series MCU interfaces
- Power Requirements – VDD range 3.0V~3.6V with 20mA~30mA current; LED backlight requires 8.4V~9.9V at 140mA
- Multiple Interface Support – Supports parallel (8080/6800), 4-wire serial, and 3-wire serial interfaces
- Operating Environment – Temperature range -20°C to +70°C suitable for industrial applications
- Touch Integration – No touch panel included, but available as a customization option
- Mounting Space – Module dimension 160.0 x 109.0 mm with 7.0mm thickness; verify mechanical clearance in your design
Frequently Asked Questions
Is this a color or grayscale display?
This is a grayscale TFT display module, not a full-color TFT. It supports 16 gray scales (4BPP), 4 gray scales (2BPP), and 2 gray scales (1BPP) configurations.
What is the viewing direction of this display?
This display has a 12 o’clock viewing direction with 6 o’clock gray scale inversion direction, making it ideal for standard industrial HMI applications.
Does this module include a touch panel?
No, this version does not include a touch panel. It is designed as a display-only module. Touch panel integration is available as a customization option.
What interface does this display use?
The module supports multiple interfaces: 8-bit parallel (8080/6800), 4-wire serial, and 3-wire serial via IF0 and IF1 pin configuration.
What is the typical power consumption?
Typical current consumption is 20mA to 30mA at 3.3V VDD, with power consumption ranging from 66mW to 108mW.
What is the LED backlight lifetime?
The LED backlight has a typical operating life of 50,000 hours at 25°C.
Can you provide samples?
Yes, sample units are available for evaluation. Please submit your requirements through the sample request form.
Is driver support available?
Yes, we provide initialization code, datasheets, and technical support for integration. The ST7511U driver IC is well-supported with readily available driver libraries.
What is the MOQ for mass production?
MOQ depends on specific configurations. Please contact our sales team for current MOQ information.
