10.1‑inch IPS TFT LCD Display Module – 1024×600, IPS Wide View (85°), 16:9 Widescreen, LVDS Interface

10.1‑inch IPS TFT LCD Display Module – 1024×600, IPS Wide View (85°), 16:9 Widescreen, LVDS Interface

Product Overview

This 10.1‑inch TFT LCD module delivers stunning widescreen visuals at a resolution of 1024 × RGB × 600 pixels with a 16:9 widescreen aspect ratio. Powered by the EK79001HN + EK73215BCGA dual‑chip driver solution (or equivalent), it features a LVDS interface, enabling high‑speed data transmission with low EMI and robust signal integrity – ideal for automotive, industrial, and multimedia applications requiring large‑format, high‑quality displays.

The panel utilizes a Normally Black, Transmissive LCD with an ultra‑wide viewing angle of 85° in all directions, delivering exceptional colour fidelity and contrast from virtually any perspective. An anti‑glare surface reduces reflections for improved readability in bright environments. With a large active area of 222.72 × 125.28 mm, a slim profile of 5.05 mm, and a wide operating temperature range (‑20°C to +70°C), this module is a premium choice for automotive infotainment, industrial HMIs, digital signage, and portable multimedia devices.

Key Features

• HD widescreen resolution – 1024×600 with 16:9 aspect ratio for crisp, detailed visuals
• Ultra‑wide IPS viewing angle – 85° in all directions for consistent colour from any perspective
• LVDS interface – High‑speed differential signalling with low EMI and excellent noise immunity
• Dual‑chip driver – EK79001HN + EK73215BCGA for proven reliability and performance
• Normally Black technology – Deeper blacks and superior contrast ratio
• Anti‑glare surface – Reduces reflections for improved outdoor readability
• Large active area – 222.72 × 125.28 mm for immersive viewing
• Ultra‑slim design – 5.05 mm thickness for sleek product designs
• Long‑life LED backlight – 50,000 hours typical, normally white
• Wide temperature range – Operating: ‑20℃ to +70℃; Storage: ‑30℃ to +80℃
• Flexible scan control – L/R and U/D pins for horizontal/vertical scan direction selection
• 6‑bit / 8‑bit input select – SELB pin for interface colour depth selection
• No touch panel – Focused on pure display performance

Technical Specifications

General Specifications

Mechanical Dimensions

Absolute Maximum Ratings

Electrical Characteristics (Typical Operation Conditions, Ta = 25°C)

LED Backlight Driving Conditions

Please refer to the complete specification document for backlight driving parameters.

Interface Pin Definition

The module uses a LVDS interface with 4 data lanes and differential clock.

Typical Applications

This large‑format display module is ideal for:

• Automotive displays – Infotainment systems, navigation, and rear‑seat entertainment
• Industrial HMIs – Large operator panels, control terminals, and process monitors
• Digital signage – Advertising displays, information kiosks, and public information systems
• Medical equipment – Patient monitors, diagnostic workstations, and imaging systems
• Portable multimedia devices – Portable TVs, media players, and gaming devices
• Building automation – Access control panels, HVAC systems, and security monitors

Note: The 16:9 widescreen landscape orientation is fixed. For portrait requirements, please consult our technical support team for alternative options.

Why Choose This Module?

• Large 10.1‑inch widescreen – 1024×600 HD resolution with 16:9 aspect ratio delivers immersive visuals for multimedia and professional applications.
• LVDS interface – High‑speed differential signalling with low EMI and excellent noise immunity, ideal for automotive and industrial environments.
• Ultra‑wide IPS viewing angle – 85° in all directions ensures consistent colour and contrast from any perspective.
• Anti‑glare surface – Reduces reflections for better visibility in bright environments.
• Comprehensive power supply – Integrated VDD, AVDD, VGH, VGL, and VCOM for simplified system design.
• Flexible scan control – L/R and U/D pins enable horizontal/vertical scan direction adjustment.
• 6‑bit/8‑bit colour select – SELB pin for interface colour depth selection.
• Proven dual‑chip driver – EK79001HN + EK73215BCGA provides reliable performance with strong ecosystem support.
• Quality assured – Manufactured in ISO9001/ISO14001 certified facilities.

Ordering Information

For volume pricing, sample requests, or technical drawings, please contact our sales team directly.

All specifications are subject to change without prior notice. Colour tone may vary slightly with temperature and driving voltage.
