JicTech 2.13-inch Tri-Color E-Paper Display Module (Model: JS0213BN01-TNG-A0)

Overview
The JS0213BN01-TNG-A0 is a 2.13-inch electrophoretic display (EPD) module capable of showing three distinct colors: black, white, and red. With its ultra-low power consumption, high resolution, and wide viewing angle, it is engineered for applications where readability, energy efficiency, and compact form factor are critical. The module interfaces via SPI and is designed for easy integration into a variety of electronic systems.

2.13 inch e paper display module high contrast e ink screen
2.13 inch e paper display module high contrast e ink screen

主な特徴

  • Tri-Color E-Paper Display: Black, white, and red outputs for enhanced visual communication

  • Ultra-Low Power Consumption: No power required to maintain a static image; deep sleep current as low as 3 µA

  • High Resolution: 250 × 122 pixels with 131 DPI for sharp text and graphics

  • Wide Viewing Angle: Near 180° visibility with anti-glare surface treatment

  • SPI Interface: Simple serial communication compatible with most microcontrollers

  • Compact & Lightweight: Outline dimensions of 29.2mm × 59.2mm × 1.0mm; weight approx. 3.29g

  • RoHS Compliant: Environmentally friendly construction

  • Wide Operating Range: 0°C to +40°C ambient temperature, 40–70% RH

Technical Specifications

パラメータ Specification
Active Area 23.705mm (H) × 48.55mm (V)
Pixel Pitch 0.1943mm × 0.1942mm
ディスプレイの色 Black, White, Red
Refresh Time 22 seconds typical (black/white/red update)
Supply Voltage (VCI) 2.2V–3.7V (3.0V typical)
インターフェース 4-wire or 3-wire SPI selectable via BS pin
FPC Connector 24-pin, 0.5mm pitch (compatible with HRS FH34SRJ34S or equivalent)
コントラスト比 20:1 typical (white/black)
Storage Temperature -20°C to +60°C

Reliability Validation & Environmental Tests

Certified for demanding applications through comprehensive testing:

Test Condition Duration Compliance
Temperature Cycling -20°C ↔ +60°C 100 cycles IEC 60068-2-14
High-Temp Operation +40°C, 70% RH 240 hrs Industrial Standard
Humidity Stress +50°C, 80% RH 240 hrs IEC 60068-2-30
Mechanical Vibration 1.15Grms, 1-200Hz 3 axes ISTA Procedure
Drop Resistance 97cm height 10 impacts ISTA 3A
Ghosting Performance ΔE00 < 2 (CIEDE2000) Full transition Optical Standard

Mechanical Specifications

Item Min Typ Max Unit
Glass Width 59.0 59.2 59.4 mm
Glass Height 29.0 29.2 29.4 mm
Thickness 0.9 1.0 1.1 mm
Weight – 3.29 – g

Absolute Maximum Ratings

パラメータ Symbol Min Max Unit
Storage Temp TST –20 +60 °C
Storage Humidity HST 40 70 %RH
動作温度 TOP 0 +40 °C
Operating Humidity HOP 40 70 %RH

Electrical Characteristics

パラメータ Symbol Min Typ Max Unit
電源電圧 VCI, VDDIO 2.2 3.0 3.7 V
Input High VIH 0.8×VCI – – V
Input Low VIL – – 0.2×VCI V
Deep Sleep Current Idslp – 3 – μA
Sleep Mode Current Islp – 20 – μA
Image Update Time – – 22 – sec

Optical Characteristics

パラメータ Min Typ Max Unit
コントラスト比 – 20:1 – –
White L* (CIE1931) 65 – – –
Red a* 37 – – –
Reflectance (White) – 37 – %

Applications

  • Electronic shelf labels (ESL) and retail signage

  • IoT sensor displays and smart badges

  • Portable medical devices and health monitors

  • Logistics and inventory tracking tags

  • Educational tools and low-power information displays

Customization & Support
JicTech offers flexible small-batch customization services, including:

  • Custom waveform development for optimized refresh performance

  • FPC length, connector type, and pinout adaptations

  • Packing and labeling according to your logistic requirements

  • Firmware support for SPI communication and power sequencing

  • Optical tuning for specific lighting conditions

Reliability & Testing
The module undergoes rigorous environmental tests, including high/low temperature operation, humidity resistance, thermal cycling, and mechanical vibration, ensuring consistent performance in real-world conditions.

Why Choose JicTech?
With deep expertise in display technologies and a strong focus on customer collaboration, JicTech provides reliable, energy-efficient E-Paper solutions tailored to your project needs. We support you from prototyping to production with technical guidance and adaptable design options to ensure seamless integration and optimal performance.



Download this product’s technical documentation and specifications.

Click here to download：PULL-SPEC-JS0213BN01-A0V0.4
