2.1-inch TFT LCD Module – 240×360 Display

Product Details & Technical Specifications

Overview
The RC2114BSC-A4 is a 2.1-inch square TFT LCD module with capacitive touch panel, offering a balanced combination of high resolution, brightness, and touch interactivity. Utilizing an a-Si TFT normally black panel and MIPI interface, it ensures low-power operation and excellent visual performance for compact embedded applications.

Key Features

Square 2.1-inch display with 480 × 480 resolution
Integrated capacitive touch panel (CTP)
High brightness: 500 cd/m² (typical)
High contrast ratio: 1000:1 (typical)
Wide viewing angle: 85° all directions
MIPI DSI interface (2 data lanes)
Long LED lifetime: 30,000 hours
RoHS compliant

Applications

Portable medical devices
Industrial handheld terminals
Wearable technology
Smart home controls
Instrumentation panels
Consumer electronics interfaces

Technical Parameters

Parameter	Specification	Notes
Display
LCD Size	2.1 inches (diagonal)	Square format
Panel Type	a-Si TFT, Normally Black, Transmissive
Resolution	480 (H) × RGB × 480 (V)	RGB stripe arrangement
Pixel Pitch	0.037 mm (H) × 0.111 mm (V)
Number of Colors	16.7M
Viewing Angle (L/R/U/D)	85° / 85° / 85° / 85°	CR ≥ 10
Contrast Ratio	800 (Min), 1000 (Typ)
Luminance	500 cd/m² (Typical)
Response Time (Ton+Toff)	30 ms (Typ), 35 ms (Max)
NTSC Color Gamut	65% (Min), 70% (Typ)
White Chromaticity (CIE)	x: 0.2959, y: 0.2870	±0.03 tolerance
Luminance Uniformity	75% (Min), 80% (Typ)
Touch Panel
Touch Type	Capacitive
Driver IC	CT1151QM
Interface	I2C (SDA, SCL, INT, RESET)	3.3V level
Electrical
Interface	MIPI DSI (2 data lanes)
Driver IC	ST7701S
Logic Supply (VCI)	2.8V – 3.0V – 3.3V
I/O Voltage (IOVCC)	1.8V
Input Logic Levels	Low: ≤0.3×VCI, High: ≥0.7×VCI
Backlight
Light Source	4 white LEDs (2 series × 2 parallel)	Double-core LED
Forward Voltage (VF)	12.0V (Typ), 13.2V (Max)
Forward Current (IF)	40 mA (Typ), 50 mA (Max)
Power Consumption	480 mW (Typ), 660 mW (Max)
LED Lifetime	30,000 hours	To 50% initial brightness
Mechanical
Module Dimensions	73.27 mm × 73.27 mm × 3.83 mm
Active Area	53.28 mm × 53.28 mm
Connector	30-pin, OMRON XF2M-3015-1A or equivalent
Environmental
Operating Temperature	–20°C to +70°C
Storage Temperature	–30°C to +80°C
Operating Humidity	10% to 90% RH	Non-condensing
Reliability
High Temp Operation	+70°C, 240 hours
Low Temp Operation	–20°C, 240 hours
High Temp Storage	+80°C, 240 hours
Low Temp Storage	–30°C, 240 hours
High Temp/Humidity Storage	+60°C, 90% RH, 240 hours
Thermal Shock	–30°C ↔ +70°C, 10 cycles	Non-operating
ESD Protection	Air: ±8 kV, Contact: ±4 kV	IEC 61000-4-2

Additional Information

Interface & Control: 2-lane MIPI DSI interface for high-speed display data; supports TE (Tearing Effect) output and PWM backlight control.
Power Sequencing: Strict power-on/off timing required (VCI → IOVCC → RESET → MIPI signals) to ensure stable initialization.
Touch Integration: Capacitive touch panel driven via I2C; includes interrupt (INT) and reset (RESET) pins for host control.
Mounting: Compact square design with through-hole or surface-mount compatibility; refer to mechanical drawings for precise placement.
Cleaning: Use only isopropyl alcohol or ethyl alcohol with a soft cloth. Avoid water, ketones, and aromatic solvents.
ESD & Handling: Operate in grounded, static-safe environments (30–60% RH recommended). Use anti-static packaging during storage and transit.
Storage: Store in sealed anti-static bags at 0–40°C, ≤80% RH, away from direct light, acids, alkalis, or corrosive gases.
Compliance: Designed to meet industrial reliability standards; RoHS compliant.

This TFT LCD Module from JicTech combines a high-resolution square display with responsive capacitive touch in an ultra-compact form factor, making it an ideal choice for space-constrained applications that demand clarity, interactivity, and durability.

Download Technical Documents

Click here to download this document：JIC RC21I4BSC-A4

All specifications are based on the official product specification sheet (Ver: 01). For mechanical drawings, signal timing diagrams, and full inspection criteria, please refer to the original document.
